Three Rolls Pigment Grinder Machine 110V 750W Ointment Milling Machine Water Cooling for Lab Paint Ink Paste Materials

About this item

• 【With 3 Rollers】—The grinding system consists of 3 horizontal shafts rollers, feed roll, middle roll and apron roll. Three rollers of this pigments mill machine with chilled alloy casting, thickness of chilled alloy layer is 15 - 25 mm, surface hardness is HS68 ~ 75.
• 【Speed Adjustable】—The machine is equipped with a black knob to adjust the grinding speed. Slow roller 32 r/min, mid roller 89 r/min, fast roller 250 r/min, can be achieved through adjustment.
• 【Water Cooling System】—In order to avoid the temperature of friction during the grinding process from destroying the ingredients in the raw materials, the grinding machine is designed with a water cooling system. Effectively control the temperature during the grinding process.
• 【Applications】—Three-roll grinder is mainly used for grinding paint, printing ink, pigments of grease paint, food, cosmetic and toothpaste and other slurry of paste form. It is the main equipment of such factory as painting and printing ink factories to porphyrize slurry of paste form.
• 【Adjustment Attentions】—Adjusting the pressure screw on the blade, the incision should be slightly higher than the center of the roll, this makes it easy scraped the materials attached to the roller surface. Typically, materials only need to be ground twice to meet requirements, but the materials difficult to grind should be ground for several times to meet requirements. The final processing fineness can reach more or less than 3 - 18μm in general (measured by fineness scraper).
• Three-roll mill consists of seat, the guide cover, the roll shaft housing, feeding copper knife, the riving knife plate, the cooling means and gears, pulleys, etc. The voltage of the machine has 2 versions, divided into AC220V and AC110V, please confirm before buying. Technical Parameters: Voltage: AC110V Motor Power: 0.75 kw Roller Material: Stainless Steel Diameter of Roller:65 mm Length of Roller: 125 mm Roller speed RPM: Slow Roller: 32 r/min Mid Roller: 89 r/min Fast Roller: 250 r/min particle size: 3-18 μm/3 times Reference Efficiency: 5kg/h Size: 440x420x400 mm Package Size: 540 x 540 x 580 mm/22.83 x 21.26 x 21.26 Inch Package Weight: 66 kg/145.2 lb Package Content: 134021 1 x Lab Three Roll Grinder Ointment Mill Machine 【With 3 Rollers】—The grinding system consists of 3 horizontal shafts rollers, feed roll, middle roll and apron roll. Three rollers of this pigments mill machine with chilled alloy casting, thickness of chilled alloy layer is 15 - 25 mm, surface hardness is HS68 ~ 75.; 【Speed Adjustable】—The machine is equipped with a black knob to adjust the grinding speed. Slow roller 32 r/min, mid roller 89 r/min, fast roller 250 r/min, can be achieved through adjustment.
